What are the main standards for surge protection device?

July 03 , 2025

1. Main standards for lightning protection application design

  IEC 62305-1:2010/GB/T 21714.1-2015 《Protection against lightning-Part 1: General principles》

  IEC 62305-2:2010/GB/T 21714.2-2015 《Protection against lightning-Part 2: Risk management》

  IEC 62305-3:2010/GB/T 21714.3-2015《Protection against lightning-Part 3: Physical damage to structures and life hazard》

  IEC 62305-4:2010/GB/T 21714.4-2015《Protection against lightning-Part 4: Eletrical and electronic systems within structures》

  GB 50057-2010《Technical Specification for Lightning Protection of Buildings》

  GB 50343-2012《Technical code for protection against lightning of building electronic information system》

  GB/T 50065-2011《Code for design of ac electrical installations earthing》

2. Main standards for surge protection device performance verification and selection guide series:

  IEC 61643-11:2011/GB/T 18802.11-2020 《Low-voltage surge protective devices(SPD)-Part 11: Surge protective devices connected to low-voltage power systems-Reguirements and test methods》

  IEC 61643-12:2020/GB/T 18802.12-2024 《Low-voltage surge protective device(SPD)-Part 12: Surge protective devices connected to low-voltage power systems-Selection andapplication principles》

  IEC 61643-21:2012/GB/T 18802.21-2016《Low-voltage surge protective devices-Part 21:Surge protective devices connected to telecommunications and signaling networks-Performance requirements and testing methods》

  IEC 61643-22:2015/GB/T 18802.22-2019《Low-voltage surge protective devices-Part 22 :Surge protective devices connected to telecommunications and signalling networks -Selection and application principles》

  IEC 61643-31:2018/GB/T 18802.31-2021《Low-voltage surge protective devices-Part 31: Surge protective devices connected to photovoltaic installations-Requirements and test methods》

  IEC 61643-32:2017/GB/T 18802.32-2021 《Low-voltage surge protective devices-Part 32: Surge protective devices connected to photovoltaic installations-Selection and application principles》

3.Main standards for surge protection device core component series:

  IEC 61643-311:2013/GB/T 18802.311-2017《Components for low-voltage surge protective devices Part 311 : Performance requirements and test circuits for gas discharge tubes(GDT)》

  IEC 61643-312:2013/GB/T 18802.312-2017《Components for low-voltage surge protective devices Part 312 : Selection and application principles for gas discharge tubes(GDT)》

  IEC 61643-321:2001/GB/T 18802.321-2007《Components for low-voltage surge protective devices Part 321: Specifications for avalanche breakdown diode(ABD)》

  IEC 61643-331:2003/GB/T 18802.331-2007 《Components for low-voltage surge protective devices-Part 331: Specification for metal oxide varistors(MOV)

  IEC 61643-341:2001/GB/T 18802.341-2007《Components for low-voltage surge protective device Part 341: Specification for thyristor surge suppressors (TSS)》

  IEC 61643-351:2016/GB/T 18802.351-2019《Components for low-voltage surge protective devices-Part 351: Performance requirements and test methods for telecommunications and signalling network surge isolation transformers (SIT)》
